CANON EOS 77D DSLR Camera
Canon’s EOS 77D DSLR camera combines advanced imaging capabilities and an intuitive design. The Canon EOS 77D DSLR camera is based on a 24.2MP sensor with DIGIC 7 processor. It offers a wide native ISO range from 100-25600 to accommodate shooting in different lighting conditions. A continuous shooting rate at 6 frames per second makes it ideal for working with moving objects. Dual Pixel CMOS Autofocus, using phase-detection, is also possible with the sensor design. This allows for fast, accurate and smooth autofocus performance, suitable for both video and stills in live view. A 45-point phase-detect autofocus system with a cross-type is available for stills shooting using the optical pentamirror.
Highlights
- 24.2MP APS-C CMOS Sensor
- DIGIC 7 Image Processor
- 3.0″ 1.04m-Dot Vari-Angle Touchscreen
- Full HD 1080p video recording at 60 fps
- 45-Point Cross-Type All-Phase-Detection AF
- Dual Pixel CMOS AF
- ISO 51200 and up to 6 fps shooting
- Built-in Wi-Fi with NFC and Bluetooth
- Top LCD with Rear Quick Control Dial
- RGB+IR 7560 Pixel Metering Sensor
In The Box
- Canon EOS 77D DSLR Camera
- Canon EF-S 18-135mm USM Lens
- Front Lens Cap
- Rear Lens Cap
- Battery Charger
- Lithium Battery
- Shoulder Strap
Specifications
IMAGING
Lens Mount
Canon EF
Canon EF-S
Canon EF-S
Camera Format
APS-C (1.6x Crop Factor)
Pixels
Actual: 25.8 Megapixel
Effective: 24.2 Megapixel
Effective: 24.2 Megapixel
Max Resolution
24 MP: 6000 x 4000
Aspect Ratio
1:1, 3:2, 4:3, 16:9
Sensor Type / Size
CMOS, 22.3 x 14.9 mm
File Formats
Still Images: JPEG, RAW
Movies: H.264, MP4
Audio: AAC
Movies: H.264, MP4
Audio: AAC
Bit Depth
14-Bit
Dust Reduction System
Yes
Memory Card Type
SD
SDHC
SDXC
SDHC
SDXC
Image Stabilization
Digital, 5-Way
FOCUS CONTROL
Focus Type
Auto & Manual
Focus Mode
Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S)
Autofocus Points
Phase Detection: 45 (45 Cross-Type)
VIEWFINDER/DISPLAY
Viewfinder Type
Pentamirror
Viewfinder Eye Point
19.00 mm
Viewfinder Coverage
95%
Viewfinder Magnification
Approx. 0.82x
Diopter Adjustment
-3 to +1 m
Display Screen
3″ Rear Touchscreen Swivel LCD (1,040,000)
Screen Coverage
95%
EXPOSURE CONTROL
ISO Sensitivity
Auto, 100-25600 (Extended Mode: 100-51200)
FLASH
Built-in Flash
Yes
AV RECORDING
Video Recording
Yes, NTSC/PAL
PERFORMANCE
Start-up Time
0.2 seconds
Shutter Lag
0.07 seconds
Self Timer
10 Seconds, 2 Seconds
Interval Recording
Yes
Connectivity
1/8″ Microphone, HDMI C (Mini), Mini-USB, USB 2.0
Wi-Fi Capable
Yes
POWER
Battery
1 x LP-E17 Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1040 mAh
AC Power Adapter
ACK-E6N, ACK-E6 ()
KIT LENS
Focal Length
18 – 135mm
Comparable 35mm Focal Length: 28.8 – 216 mm
Comparable 35mm Focal Length: 28.8 – 216 mm
Aperture
Maximum: f/3.5 – 5.6
Angle of View
74° 20′ – 11° 30′
Minimum Focus Distance
1.28′ (39 cm)
Elements/Groups
16/12
Autofocus
Yes
Image Stabilization
Yes
Filter Thread
Front: 67 mm
Dimensions (DxL)
Approx. 3.05 x 3.78″ (77.4 x 96 mm)
Weight
1.13 lb (515 g)
